MC RF Driver MC200A AMP MODULE
MC Series RF driver and amplifier solution for compatible acousto-optic devices, supporting integration into laser and photonics systems.
Full Product Description- Stock Code:
- 97-03282-01
- RF Frequency Min (MHz):
- 200
- RF Frequency Max (MHz):
- 200
- RF Power Per Channel (W):
- 2.5
- AO Compatibility:
- AOMC
Product description
The G&H MC Series provides RF drive and amplification solutions for compatible multi-channel acousto-optic modulators. The family supports applications requiring coordinated laser modulation, optical switching or beam control across multiple channels. It can be integrated into scientific, industrial and OEM photonics platforms, with different configurations available to suit the associated AO device and RF architecture. Refer to the product datasheet and specifications and special notes on this page for the current configuration and integration requirements of this model.
Key features
- RF drive or amplification for compatible acousto-optic devices and multi-channel modulators
- Channel configuration options across the range
- Amplifier-only options for externally supplied RF signals
- Integrated oscillator and amplifier options on selected variants
- Acousto-optic device operation
- OEM photonics system integration
- RF amplification for systems with external oscillators
- Acousto-optic systems requiring multiple RF channels
Specifications
| Name | Value |
|---|---|
| Stock Code | 97-03282-01 |
| Model | MC RF Driver MC200A AMP MODULE |
| Frequency Control | Fixed |
| RF Frequency Min (MHz) | 200 |
| RF Frequency Max (MHz) | 200 |
| RF Power Per Channel (W) | 2.5 |
| Modulation Control | Analog |
| Supply Voltage (V) | 28 |
| Cooling | Forced Air |
| AO Compatibility | AOMC |
| Special Notes | Amplifier Only. Requires user supplied oscillator input.; For service only. Replacement option for 1ch repair. |
(Values for Guidance Only - refer to datasheet where available)
